HMI30 / HMI30-TF User’s guide
Note:
For installation in control cabinets and, in
particular, in closed containers, make sure
the recommended ambient temperature is
maintained.
For further details please refer to section
8.1 Technical specifications.
Figure 19
Mounting position
3.4 Mounting position
The HMI device is suitable for installation in:
 Mounting cabinets
 Control cabinets
 Switchboards
 Consoles
3.4.1 Damage due to overheating
 The operative temperature must be between 0° and 50°C.
 All HMI systems are designed for vertical mounting position.
 An inclined installation reduces the thermal convection by the HMI de-
vice and the maximum permissible ambient temperature for operation.
Please contact ASEM for details.
 The HMI device may otherwise be damaged and its certifications and
warranty will be void.
