65
HMI30 / HMI30-TF User’s guide
Table 34
5.7” display characteristics
Table 35
7.0” display characteristics
Table 36
5.4” display characteristics
7.1.1 5.7” display characteristics
5.7” display characteristics
Dimensions
5.7” (4:3)
Technology
TFT active matrix
Display area
115.2 (W) x 86.4 (H) mm
Resolution
640 x 480 pixels
Display color
256 K colors
Pixel Pitch
0.18 (W) x 0.18 (H) mm
Luminance
500 cd/m
2
Horizontal viewing angle
(left + right)
100
◦
Vertical viewing angle
(up + down)
140
◦
Contrast ratio
250:1
Response time (Rise)
50 ms (Typ.)
Backlight
LED
7.1.2 7” display characteristics
7” display characteristics
Dimensions
7” wide (15:9)
Technology
TFT active matrix
Resolution
800 x 480 pixels
Display color
256 K colors
Pixel Pitch
0.1905 (W) x 0.1905 (H) mm
Luminance
350 cd/m
2
Horizontal viewing angle
(left + right)
140
◦
Vertical viewing angle
(up + down)
130
◦
Contrast ratio
400:1 (Typ.)
Response time (Rise)
10 ms
Backlight
LED
7.1.3 8.4” display characteristics
8.4” display characteristics
Dimensions
8.4” (4:3)
Technology
TFT active matrix
Display area
170.4 (W) x 127.8 (H) mm
Resolution
800 x 600 pixels
Display color
256 K colors
Pixel Pitch
0.213 (W) x 0.213 (H) mm
Luminance
350 cd/m
2
Horizontal viewing angle
(left + right)
150
◦
Vertical viewing angle
(up + down)
130
◦
Contrast ratio
600:1 (Typ.)
Response time (Rise)
10 ms (Typ.)
Backlight
LED
