ASEM HMI30 - Configuration; HMI30 (Full Aluminium Front Panel); HMI30-TF (Aluminium Front Panel with True Flat Technology); Figure 1 HMI30 5.7

9
HMI30 / HMI30-TF User’s guide
Figure 1
HMI30 5.7”
Figure 2
HMI30-TF 5.7”
2.4 Configuration
The following figures show the various configurations.
2.4.1 HMI30 (full aluminium front panel)
HMI30
5.7”
Full aluminum front panel
7.0” Wide
8.4”
10.4”
12.1”
15.0”
2.4.2 HMI30-TF (aluminium front panel with true flat
technology)
HMI30-TF
5.7”
Aluminium front panel with True
Flat technology
7.0” Wide
8.4”
10.4”
12.1”
15.0”
