SECTION 8 - Technical specifications
Table 31
Displays
Table 32
Measuraments
Table 33
Warranty & approvals
Displays
5,7”
LCD Size
5,7”
Resolution
640 x 480 (VGA)
Colors
256K
Backlight
Sidelight LED
7” W
LCD Size
7” Widescreen
Resolution
800 x 480 (WVGA)
Colors
256K
Backlight
Sidelight LED
8,4”
LCD Size
8,4”
Resolution
800 x 600 (SVGA)
Colors
16M
Backlight
Sidelight LED
10,4”
LCD Size
10,4
Resolution
800 x 600 (SVGA)
Colors
16M
Backlight
Sidelight LED
12,1”
LCD Size
12,1”
Resolution
800 x 600 (SVGA)
Colors
16M
Backlight
Sidelight LED
12,1”
LCD Size
12,1”
Resolution
1024 x 768 (XGA)
Colors
16M
Backlight
Sidelight LED
15,0
LCD Size
15,0”
Resolution
1024 x 768 (XGA)
Colors
16M
Backlight
Sidelight LED
Dimensions
5,7”
Full Aluminium (W x H x D)
175 x 145 x 40
True Flat Alu (W x H x D)
175 x 145 x 40
Cutout (W x H)
164 x 134
7” W
Full Aluminium (W x H x D)
215 x 155 x 40
True Flat Alu (W x H x D)
215 x 155 x 40
Cutout (W x H)
204 x 144
8,4”
Full Aluminium (W x H x D)
255 x 190 x 48,5
True Flat Alu (W x H x D)
255 x 190 x 48,5
Cutout (W x H)
243 x 179
10,4”
Full Aluminium (W x H x D)
245 x 230 x 48,5
True Flat Alu (W x H x D)
245 x 230 x 48,5
Cutout (W x H)
283 x 219
12,1”
Full Aluminium (W x H x D)
325 x 260 x 48,5
True Flat Alu (W x H x D)
325 x 260 x 48,5
Cutout (W x H)
313 x 249
15,0”
Full Aluminium (W x H x D)
390 x 305 x 48,5
True Flat Alu (W x H x D)
390 x 305 x 18,5
Cutout (W x H)
378 x 294
Warranty & approvals
CE
Emission
Conforms to EN 55022 Information technology equipment Radio dis-
turbance characteristics
Immunity
Conforms to EN 55024 Information technology equipment Immunity
characteristics
Safety
Conforms to EN 60950-1 Information technology equipment Safety
