HMI30 / HMI30-TF User’s guide
Figure 9
HMI30 5.7” rear view
Note: rear panels may be different
depending on display size.
Figure 10
HMI30 7.0” rear view
Note: the user manual refers to HMI
5.7” version. Other versions will be dis-
cussed only when necessary.
2.6 Rear view
Ventilation holes
Mounting seal
7.0”
Ventilation holes
Mounting seal
1
2
1
2
1
2
1
2
