Aspen Avionics EFD1000 - Page 145

EFD1000 Installation Manual
DOCUMENT # A-01-126-00 PAGE 145-225 Revision H
© Copyright 2009 Aspen Avionics Inc.
FEATURE PAGE/KEY
ASSIGNMENT
AVAILABLE
OPTIONS/RANGE
EFD1000 CONFIGRATION PER AIRCRAFT
NOTED ABOVE
MISC CONFIG PAGE PAGE 4:11 PAGE 4 OF 11
MISC CONFIG
RSM GPS Enable KEY 1 DISABLE / ENABLE
RSM GPS Usage KEY 2 EMER ONLY / VFR EMER ONLY
Electrical System KEY 3 14 VOLT /
28 VOLT
Pitch Attitude Trim KEY 4 Editable:
-10.0 to +10.0
Roll Attitude Trim
(PFD SW v1.1 and later)
KEY 5 Editable:
-10.0 to +10.0
Configuration Module Z-axis
Scale Factor
(SW v1.1 only, see SB 2009-
02)
Via SD card Editable:
0.6 to 1.0
NAVIGATION
CONFIGURATION SET UP
PAGE 5:11 PAGE 5 OF 11
NAV SET UP
GPS / NAV #1
Configuration
KEY 1
NONE, A, B, C, D, E,
F, G, H, I, J, K, L, M,
P, Q, R
GPS / NAV #2
Configuration
KEY 2
NONE, A, B, C, D, E,
F, G, H, I, J, K, L, M
Composite Phase
(VOR1,VOR2)
(PFD SW v1.1 and later)
KEY 5 (0,0); (180,0);
(0,180);(180,180)
429 PORT
CONFIGURATION PAGE
PAGE 6:11 PAGE 6 OF 11
A429 CONFIG No Configuration Required
RS232 PORT
CONFIGURATION PAGE
PAGE 7:11 PAGE 7 OF 11 No Configuration Required
RS232 CONFIG
NAVIGATION SOURCES
CONFIGURATION
PAGE 8:11 PAGE 8 OF 11 No Configuration Required
NAV CONFIG
RS-232 SETUP
(PFD SW v1.1 and later)
KEY 5 NORMAL, WPT
ONLY
NORMAL
(WPT ONLY is Not Authorized)
ACU CONFIGURATION
PAGE
PAGE 9:11 PAGE 9 OF 11
ACU CONFIG
ACU HSI TYPE: KEY 1 0,1
ACU FD TYPE: KEY 2 0,1,3,4
ACU DATUM: KEY 3 NORMAL,
REVERSED
FD ROLL OFFSET ADJ: KEY 4 +/- 7.5 units (0.5
unit increments)
FD PITCH OFFSET ADJ: KEY 5 +/- 7.5 units (0.5
unit increments)
