EFD1000 PFD Software Version 1.0 requires that the “HDG OFFSET” field, as described in 10.5.3.1, be
recorded below.
RSM CALIBRATION
(PFD Software 1.0 only)
PAGE 10:11 PAGE 10 OF 11
RSM CALIBRATION
HDG OFFSET: KEY 5 Editable: -10 to
+10 degrees
EFD1000 PFD Software Version 1.1 and later requires that the “HDG ADJ” field for each 30º heading
increment between 30º to 360º, as described in section 10.5.3.2, be recorded below.
RSM CALIBRATION
(PFD Software 1.1 and
later
PAGE 10:11
PAGE 10 OF 11
RSM CALIBRATION
HDG SEL: 030 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 060 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 090 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 120 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 150 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 180 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 210 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 240 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 270 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 300 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 330 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
HDG SEL: 360 KEY 4
HDG ADJ: KEY 5 Editable: -6 to +6
ACCEL BIAS CAL PAGE 11:11 PAGE 11 OF 11 No Configuration Required
ACCEL BIAS CAL
Table 10.1 – EFD1000 System Configuration Chart
