Ch. 10. Environmental Scanner Overview Sec. 10.3. Cypher ES Quick Reminder List
3.
Be careful when reattaching the cantilever
clip to not crack the glass.
• Anytime the cantilever clip has been
completely removed - for cleaning - care
must be taken when reattaching the clip.
• Do not tighten the screw until you are
sure that the clip is aligned correctly and
has dropped into the pocket in the glass
body.
Warning: Pay attention! Failure to align the
cantilever clip with the pocket before
tightening the clip will break the cantilever
holder glass.
4.
Use extra care when loading the Heater
sample stage.
• The heater sample stage is extremely
fragile. Only use minimal force when
seating the sample stage dovetail against
the scanner.
• If you use your finger to push the stage
down into the scanner, you should only
need enough pressure to extend the
diaphragm. Any more pressure will
break the heater. If it is taking more
pressure to push the dovetail into the
scanner, simply push the dovetail over
(with a wrench from the bottom of the
sample stage) until it drops into the
scanner.
• It is a good idea to wear gloves when
doing this so that you minimize finger
grease getting cooked onto the heater
stage.
Warning: Do not apply force to heater sample stage. It is fragile!
Warning: Pay attention! If you apply too
much force to the heater stage you will break
it.
DRAFT
Page 127
