Ch. 13. Cell Body and Sample Stage GuideSec. 13.3. Sample Stage / Cell Body Disassembly
3.
Extend the membrane:
• Place the assembly as shown.
• Pull on the sample stage bottom and extend the membrane as shown.
4.
Loosen all the screws:
• Using a 1.7mm flat tipped screwdriver, loosen all the screws.
NOTE: Be careful not to slip and possibly puncture the membrane with the screwdriver.
5.
Remove the ring:
• Remove the retaining ring and set it and
the screws aside.
DRAFT
Page 160
