Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
4. Set down the view module, then set aside the 2 screws and the L-key tool.
5.
Use Kapton tape to secure lens tissue over the
view module lens.
6. Put it in a plastic bag and tape shut.
7.
Put it in the view module foam, which has
asquare spot in the far corner.
8. Tape the 2 screws and the L-key tool to the view module bag for safekeeping.
9.
• First, locate the clear plastic objective
container with the black cap. Remove
the black cap and have it sitting ready.
• Remove the objective from the chassis
by unscrewing it. Be careful as it is both
very fragile and very expensive.
• Immediately screw the objective to the
black cap, followed by the clear plastic
cover.
• Always store the objective in this
container. If you do not have one, please
contact Asylum Research for a spare.
BETA
Page 253
