Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
c)
Slide the light cube out carefully.
d) Turn the clamping screw to close – only ¼ turn back – DO NOT OVER TIGHTEN! (See
Figure in Step 1a on page 255)
2. Tape down the clamping screw.
3.
Tape both the phone cable & the laser module
cable to the top bridge of the chassis in the
center.
4.
Put lens tissue and Kapton tape over the hot
mirror and wrap tape around to cover the side
port hole.
BETA
Page 256
