Chapter 3 – Start-up and adjustments
UM-22100H-U User manual ATEQ D520 Page 39/122
2.3.11. Range (second capillary option)
The second capillary is an option on the D520 instrument, it allows having two flow
measurement ranges so that to have best adapt of the measurement extend of the
capillary in function of the part to be controlled.
When this option exists in the instrument, the "Range" parameter appears in the
parameters menu, so you have to choose the capillary (the range), then the best
measurement range adapted to the part to be controlled.
The choice of the range is function of the capillaries installed in the instrument: the
available ranges are: 5 l/h, 30 l/h, 150 l/h, 500 l/h, 1500 l/h, 4000 l/h and 10000 l/h.
) Adjust this parameter according to the method described in § 2.3.
2.3.12. Functions
The FUNCTION menu allows access to additional parameters which must first be
activated in the CONFIGURATION menu, then in EXTENDED MENUS.
If no additional parameters have been activated in the EXTENDED MENUS, the
FUNCTION menu is empty.
To activate these parameters, refer to chapter 4 § 2.
