User's Manual Contents
Version 3.0 103 430HD and 440HD IP Phone
Figure 7-18: Popup Menu
2. Select the Phone Pairing option
Figure 7-19: Phone Pairing
3. In the 'Type the pair code' screen, enter the pair code that you generated as shown in
Section 7.1.6.1; the OK button is activated after 8 characters are entered.
3. Click the OK button; BToE is activated.
4. If a communication error occurs or the wrong pair code was entered, the following icon
indication appears:
Figure 7-20: AC BToE Failed Indication
5. When BToE is successfully connected, view the following icon indication:
Figure 7-21: AC BToE is Connected Indication
6. When BToE is in 'Connected' state, the popup menu shows the Disconnect menu item
and the Phone Pairing menu item is deactivated:
