AudioCodes Mediant 2000 System - Page 91

Version 5.2 91 September 2007
SIP User's Manual 5. Web-based Management
Table 5-9: Proxy & Registration Parameters
Parameter Description
Use Routing Table for
Host Names and
Profiles
[AlwaysUseRouteTabl
e]
Use the internal Tel to IP routing table to obtain the URI Host name and
(optionally) an IP profile (per call), even if Proxy server is used.
 [0] Disable = Don't use (default).
 [1] Enable = Use.
Note: This domain name is used, instead of Proxy name or Proxy IP
address, in the INVITE SIP URI.
Always Use Proxy
[AlwaysSendToProxy]
 [0] Disable = Use standard SIP routing rules (default).
 [1] Enable = All SIP messages and Responses are sent to Proxy server.
Note: Applicable only if Proxy server is used (i.e., IsProxyUsed = 1).
Send All INVITE to
Proxy
[SendInviteToProxy]
 [0] No = INVITE messages, generated as a result of Transfer or Redirect,
are sent directly to the URI (according to the Refer-To header in the
REFER message or Contact header in 30x response) (default).
 [1] Yes = All INVITE messages, including those generated as a result of
Transfer or Redirect are sent to Proxy.
Note: Applicable only if Proxy server is used and AlwaysSendtoProxy = 0.
Enable Proxy Hot-Swap
[IsProxyHotSwap]
Enable Proxy Hot-Swap redundancy mode.
 [0] Disable = Disabled (default).
 [1] Enable = Enabled.
If Hot Swap is enabled, SIP INVITE/REGISTER message is first sent to the
primary Proxy/Registrar server. If there is no response from the primary
Proxy/Registrar server for HotSwapRtx retransmissions, the
INVITE/REGISTER message is resent to the next redundant Proxy/Registrar
server.
Proxy / Registrar Registration parameters (the parameter fields appear only if 'Enable Registration'
is enabled)
Enable Registration
[IsRegisterNeeded]
Enables the gateway to register to Proxy / Registrar server.
 [0] Disable = gateway doesn't register to Proxy / Registrar (default).
 [1] Enable = gateway registers to Proxy / Registrar when the device is
powered up and every RegistrationTime seconds.
Note: The gateway sends a REGISTER request for each channel or for the
entire gateway (according to the AuthenticationMode parameter).
Registrar Name
[RegistrarName]
Registrar Domain Name. If specified, the name is used as Request-URI in
REGISTER messages. If it isn't specified (default), the Registrar IP address
or Proxy name or Proxy IP address is used instead.
