3 Physical Description for OSN-Based
Devices
This section provides a brief description of the front and rear panels of the device. For a
detailed description, refer to the following documents:
 Mediant 800 Gateway and SBC Hardware Installation Manual
 Mediant 1000B Gateway and SBC Hardware Installation Manual
3.1 Mediant 800B/800C Front-Panel Description
The front panel of the device provides various port interfaces for the optional SBC-Gateway
functionality.
Figure 3-1: Mediant 800B Front Panel
Figure 3-2: Mediant 800C Front Panel
Note:
• The telephony interfaces are customer-ordered items and not shipped by default.
• The figure above is used only as an example. The number and type of interfaces
depend on the ordered configuration.
