Installation and Maintenance Manual 60 LTRT-33443
Mediant SBA
Figure 6-2: Configuration Example Proxy Sets in Proxy Sets Table
Index Name
SBC IPv4
SIP
Interface
TLS Context
Name
Proxy
Keep-Alive
Proxy Hot
Swap
Proxy
Load
Balancing
Method
1
SIPTrunk
(arbitrary name)
SIPTrunk Default
Using
Options
- -
2
Teams
(arbitrary name)
Teams Teams
Using
Options
Enable
Random
Weights
3
SBA Teams
(arbitrary name)
Teams Teams
Using
Options
Enable -
6.1.1 Configure Proxy Addresses
This section shows how to configure a Proxy Address.
To configure a Proxy Address for SBA Teams:
1. Open the Proxy Sets table (Setup menu > Signaling & Media tab > Core Entities
folder > Proxy Sets), click the Proxy Set SBA Teams, and then click the Proxy
Address link located below the table; the Proxy Address table opens.
2. Click +New; the following dialog box appears:
Figure 6-3: Configuring Proxy Address for Teams Direct Routing SBA Interface
3. Configure the address of the Proxy Set according to the parameters described in the
table below:
Figure 6-4: Configuration Proxy Address for SIP Trunk
Index Proxy Address
Transport
Type
Proxy
Priority
Proxy
Random
Weight
0
Teams DR-SBA FQDN:5061
(DR-SBA FQDN / port)
TLS 0 0
4. Click Apply.
Note: The proxy set should connect to SIP interface that must listen on TLS 5061 and must
be routable to DR-SBA.
