Installation and Maintenance Manual 82 LTRT-33443
Mediant SBA
10.3 SBC/Gateway-Related Operations
If you are also using your device for SBC/Gateway functionality (i.e., PSTN Gateway and/ or
SBC), you can use the SBA Management Interface for various Gateway-related operations,
as described in this section.
Note:
To enable communication between the SBA Management Interface and the
Gateway's Web interface, ensure Internal VLAN is enabled (OSNInternalVLAN=1).
10.3.1 Viewing Gateway Information
The following subsections describe how to view various information relating to the Gateway.
10.3.1.1 Viewing Gateway Details
The following procedure describes how to view details about the Gateway.
To view gateway details:
1. From the Monitor menu, select the Dashboard folder, and then click Dashboard.
2. Scroll down the page to the SBC/Gateway section:
Figure 10-14: Viewing Gateway Details
The following information is displayed:
Product Name: Name of the Gateway model
Product Version: Software version currently running on the Gateway
IP Address: IP address of the Gateway's OAMP interface
Serial Number: Serial number of the Gateway's CPU
MAC Address: MAC address of the Gateway
10.3.2 Accessing Gateway's Web Interface
If required, you can access the Gateway's Web interface from the SBA Management
Interface. The Gateway's Web interface allows you to fully configure Gateway functionality.
To access the gateway's Web interface:
1. From the Monitor menu, select the Dashboard folder, and then click Dashboard.
2. Scroll down the page to the SBC/Gateway section, and then click ; the Web
interface of the Gateway opens.
For more information on using the Gateway's Web interface, refer to the Gateway's User's
Manual.
