Installing the S8700 IP Connect
May 2002
Sample Port Network Status Screen for Cabinet 1—S8700 Multi-Connect
Check Circuit Pack Configuration
The list configuration report provides a list of circuit packs connected to the configuration and
recognized by the software.
1 Type list configuration all and press Enter.
2 Verify the screen displays list configuration similar to ‘‘Sample System Configuration
Screen — Page 4, S8700 Multi-Connect’’ on page 191. Make sure the software is
communicating with each circuit pack (except power supply circuit packs). Do not
attempt to correct any problems until after the diagnostic tests that you run later in the
configuration tests.
3 Note any boards with a VINTAGE column entry of NO BOARD or CONFLICT.
4 A u indicates unassigned ports, and a number indicates the port has been translated.
status port-network 1
PORT NETWORK STATUS
Major Minor Warning Carrier PN Control FIBER-
PN Alarms Alarms Alarms Locs Active Standby LINK Endpoints Mode
1 1 0 195 01A up up 1 B-PNC 01B02-03E04 standby
01B 1 A-PNC 01A01-01E04 active
TDM Service Control Dedicated TONE/ Service System System
Bus State Channel Tones CLOCK State Clock Tones
A in y n 01B in standby standby
B in n y 01A in active active
Service Major Minor Bus Open Bus
PKT State Alarms Alarms Faults Leads
1 in n n 0 0
Command:
