89
Installing the S8700 IP Connect
May 2002
• A 10 BaseT Ethernet connection into your LAN for the TN799DP.
• Two or more valid, unused IP addresses on the network (one for each TN2302AP and
one for each C-LAN) that can be assigned to the IP Media Processor server. You also
need the subnet mask and default gateway.
NOTE:
Get this information from the network administrator or refer to the job aid entitled
Pre-Installation Network Worksheet—S8700 IP Connect or Pre-Installation Network
Worksheet—S8700 Multi-Connect.
Check your shipment
When the order arrives at your site, check the contents (see ‘‘Required Hardware’’ on page 89
).
1 Inspect the shipping carton for damage before opening it. If the box is damaged, do not
open it. Inform the shipping company, and ask for instructions on filing a claim.
2 If the box is undamaged, check the contents against the packing slip. Check the condition
of each component, and note any damage or shortages on the packing slip. The carton
should contain the items in ‘‘Required Hardware’’ on page 89
for each TN2302AP IP
Media Processor ordered.
3 Read and follow any directions inserted into the package by the factory.
NOTE:
The customer must provide one CAT5 or better cable for each TN2302AP.
Required Hardware
Comcode/Code Description Quantity
108312612 TN2302AP IP Media Processor 1
848525887 TN2302AP Amphenol Adapter
1
1
108525528 TN799DP C-LAN circuit pack.
One TN799DP supports more than one
TN2302AP.
1
102631413 ADPTR-259A connector 1
1
The adapter has an amphenol connector on one side and an RJ45 connector on the other
for connecting to the network. See ‘‘TN2302AP Amphenol Adapter’’ on page 90
.
