Setup > Meter > Fluid
Fluid Submenus Options/Descriptions
FLUID
Water - Tap Acetone Ethylene Glycol 30% Kerosene Propylene Glycol 30%
Raw Sewage Ammonia Gasoline Methanol Stoddard Solvent
Water - Distilled Benzene Glycerin Oil Diesel #1 Sulfuric Acid 96%
Water - Sea 3.5% Ethanol Isopropanol Oil Diesel #2 Hydrochloric Acid 36%
Brine - 3.5% Ethylene Glycol 100% Jet Fuel A1/JP8 Propylene Glycol 100% Hyrdrofluoric Acid 49%
Brine - 10% Ethylene Glycol 50% Jet Fuel B/JP4 Propylene Glycol 50% Custom
CUSTOM FLUID
SOUND SPEED Numeric entry; Units ft/s or m/s based on velocity units.
SPEED UNITS Ft/s or m/s
SPECIFIC GRAVITY
Numeric entry; Specific gravity (density relative to water), pipe size and viscosity are used
to calculate the Reynolds number. The Reynolds number indicates whether the fluid is in
turbulent, transition or laminar flow and the flow profile.
VISCOSITY Numeric entry; Units centipoise (cP) or mPa-s. Dynamic viscosity of the fluid.
VISCOSITY UNITS Units centipoise (cP) or mPa-s
REFERENCE TEMP Numeric entry, F or C. Default 15° C. Reference temperature of viscosity and specific gravity.
REF TEMP UNITS F or C
SPECIFIC HEAT
Numeric entry; Units: joule/gram °C; min. 0.01, max. 65.0; Specific heat capacity is the heat
capacity per unit mass of a material.
Setup > Meter > Flow Setup
An asterisk (*) indicates the parameter default.
Flow Setup Submenus Options/Descriptions
DIRECTION
*FORWARD
REVERSE
BIDIRECTIONAL
*ENABLED
DISABLED
LOW FLOW CUTOFF Numeric entry. Units and decimals are based on FLOW RATE UNITS. Zero and positive values. *0.0
SIGNAL CUTOFF *30%
SIGNAL HIGH *90%
MINIMUM FLOW -10000 (default); min. -2,000,000. Number of decimals points depends on Home Screen settings.
MAXIMUM FLOW 10000 (default); max. 2,000,000
Parameter Descriptions by Menu
Page 27 October 2019 TTM-UM-02222-EN-04
