TFX-5000 Flow Meters for Pipes 2.5 in. and Larger for Hazardous Locations
DQ
-
B
- - - - - - -
XX
- -
Model
TFX-5000 Ultrasonic Clamp-On Meter DQ
Certification
Hazardous Location, Class I, Division 2
B
Transducer Type
Medium pipe, 2.5 in. (65 mm) or larger RZ
Medium pipe, submersible, 2.5 in. (65 mm) or larger
1
WZ
Large pipe, 8 in. (200 mm) or larger LZ
Large pipe, submersible, 8 in. (200 mm) or larger
1
YZ
Transmitter Type
110/220V AC Remote Mounted R
24V DC/AC Remote Mounted B
Display
Standard S
No Display/Keypad W
Remote Cable/Conduit Length
2
15 feet (4.5 m) AC AC
30 feet (9 m) AF AF
50 feet (15 m) AK AK
75 feet (23 m) AR AR
100 feet (30 m) BW BW
150 feet (46 m) BK BK
200 feet (61 m) DW DW
250 feet (76 m) DK DK
300 feet (90 m) EW EW
Hardware
1/2 in. NPT Threads, Poly cable glands S
1/2 in. NPT Threads, Nickel Plated Brass cable glands T
1/2 in. NPT Threads, no cable glands N
M20 Threads, Poly cable glands C
M20 Threads, Nickel Plated Brass cable glands D
M20 Threads, no cable glands A
Endpoint Wiring Method
None XX
Communication/Output
Standard Output (Modbus RTU or BACnet MS/TP field selectable) S
Standard Output plus Modbus TCP Ethernet T
Standard Output plus EtherNet/IP U
Standard Output plus BACnet/IP Ethernet V
Units of Measure Totalizer/Flow Rate
Gallons/gallons per minute (field selectable, additional options available) G
Testing & Tagging
Factory Calibrated
F
Factory Calibrated/Stainless Steel Tag
S
1
Submersible transducer cables use two conduit openings.
2
For hazardous location units, Remote Cable and Conduit Length codes must match.
Part Number Construction
Page 56 October 2019TTM-UM-02222-EN-04
