Badger Meter Dynasonics TFX-5000 User Manual

TFX-5000 Flow Meters for Pipes 2 in. and Smaller for Hazardous Locations
DQ
-
B
- - - - - -
XX
- - -
Model
TFX-5000 Ultrasonic Clamp-On Meter DQ
Certification
Hazardous Location, Class I, Division 2 B
Transducer Type
1
1/2 inch ANSI Pipe CA
3/4 inch ANSI Pipe CB
1 inch ANSI Pipe CC
1-1/4 inch ANSI Pipe CD
1-1/2 inch ANSI Pipe CE
2 inch ANSI Pipe CF
1/2 inch Copper Tube CG
3/4 inch Copper Tube CH
1 inch Copper Tube CT
1-1/4 inch Copper Tube CJ
1-1/2 inch Copper Tube CK
2 inch Copper Tube CL
Transmitter Type
110/220V AC Remote Mounted R
24V DC/AC Remote Mounted B
Display
Display and Keypad S
No Display/Keypad W
Remote Cable/Conduit Length
2
15 feet (4.5 m) AC AC
30 feet (9 m) AF AF
50 feet (15 m) AK AK
75 feet (23 m) AR AR
100 feet (30 m) BW BW
Hardware
1/2 in. NPT Threads, Poly cable glands S
1/2 in. NPT Threads, Nickel Plated Brass cable glands T
1/2 in. NPT Threads, no cable glands N
M20 Threads, Poly cable glands C
M20 Threads, Nickel Plated Brass cable glands D
M20 Threads, no cable glands A
Endpoint Wiring Method
None XX
Communication/Output
Standard Output (Modbus RTU or BACnet MS/TP field selectable) S
Standard Output plus Modbus TCP Ethernet T
Standard Output plus EtherNet/IP U
Standard Output plus BACnet/IP Ethernet V
Units of Measure Totalizer/Flow Rate
Gallons/gallons per minute (field selectable, additional options available) G
Testing & Tagging
Factory Calibrated
F
Factory Calibrated/Stainless Steel Tag
S
1
Stainless steel tube 1/2…2 in. options are available.
2
For hazardous location units, Remote Cable and Conduit Length codes must match.
Part Number Construction
Page 54 October 2019TTM-UM-02222-EN-04
