Badger Meter Dynasonics TFX-5000 User Manual

PART NUMBER CONSTRUCTION
TFX-5000 Flow Meters for Pipes 2 in. and Smaller
DQ
-
G
- - - - - - -
XX
- - -
Model
TFX-5000 Ultrasonic Clamp-On Meter DQ
Certification
General Area US/Canada, CE G
Transducer Type
1
1/2 inch ANSI Pipe CA
3/4 inch ANSI Pipe CB
1 inch ANSI Pipe CC
1-1/4 inch ANSI Pipe CD
1-1/2 inch ANSI Pipe CE
2 inch ANSI Pipe CF
1/2 inch Copper Tube CG
3/4 inch Copper Tube CH
1 inch Copper Tube CT
1-1/4 inch Copper Tube CJ
1-1/2 inch Copper Tube CK
2 inch Copper Tube CL
Small pipe, universal (not available with conduit) UZ
Transmitter Type
110/220V AC Remote Mounted R
24V DC/AC Remote Mounted B
Display
Display and Keypad S
No Display/Keypad W
Remote Cable Length
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
Conduit Type and Length (Conduit length is less than or equal to cable length)
None WW
5 feet (1.5 m) AA
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
Hardware
1/2 in. NPT Threads, Poly cable glands S
1/2 in. NPT Threads, Nickel Plated Brass cable glands T
1/2 in. NPT Threads, no cable glands N
M20 Threads, Poly cable glands C
M20 Threads, Nickel Plated Brass cable glands D
M20 Threads, no cable glands A
Endpoint Wiring Method
None XX
Communication/Output
Standard Output (Modbus RTU or BACnet MS/TP field selectable) S
Standard Output plus Modbus TCP Ethernet T
Standard Output plus EtherNet/IP U
Standard Output plus BACnet/IP Ethernet V
Standard Output plus Aux Output 9
Units of Measure Totalizer/Flow Rate
Gallons/gallons per minute (field selectable, additional options available) G
Testing & Tagging
Factory Calibrated
F
Factory Calibrated/Stainless Steel Tag
S
1
Stainless steel tube 1/2…2 in. options are available.
Part Number Construction
Page 53 October 2019 TTM-UM-02222-EN-04
