Setup > Communications
Requires service level passcode or higher if security is enabled. For addressing information, see the "TFX-5000 Meter Modbus
RTU Protocol" user manual or the "TFX-5000 Meter BACnet MS/TP Protocol" user manual, available at www.badgermeter com.
An asterisk (*) indicates the parameter default.
Communication
Submenus
Options/Descriptions
EIA-485 TYPE
DISABLE
Either disable this feature or select a network type.*MODBUS RTU
BACNET MS/TP
MODBUS RTU
SETTINGS
(Displayed when
MODBUS RTU is
selected as the
option for
EIA-485 TYPE.)
ADDRESS Numeric entry 1…254
BAUD RATE *AUTO, 9600, 19200, 38400, 57600, 76800, 115200
ACCESS
WRITE/READ allows full access.
RESET/READ allows you to read any, but only write to Flow Total Reset (cannot set up meter).
READ ONLY allows read only.
PARITY
*NONE
ODD PARITY
EVEN PARITY
STOP BIT
*1 STOP BIT
2 STOP BITS
RESISTOR
*DISABLED
ENABLED
WORD ORDER
BIG ENDIAN
*LITTLE ENDIAN
TIMEOUT Numeric entry 0…10000 ms
BACNET MS/TP
SETTINGS
MAC ADDRESS Numeric entry 0…127
BACNET ID Numeric entry 0…4194303
BAUD RATE *9600, 19200, 38400, 57600, 76800, 115200
ACCESS
WRITE/READ allows full access.
RESET/READ allows you to read any, but only write to Flow Total Reset (cannot set up meter).
READ ONLY allows read only.
MAX MASTER Numeric entry 1…127
PARITY
*NONE
ODD PARITY
EVEN PARITY
STOP BIT
*1 STOP BIT
2 STOP BITS
RESISTOR
DISABLED
*ENABLED
ENDPOINT
Select the settings to match the BEACON/AquaCUE settings. Only the flow total selected for the Home Screen will be
sent. Energy totals are not supported.
DIAL COUNT 7, *8, 9, 10
RESOLUTION *OFF, 1, 10, 100, 1000, 10000, 0.1, 0.01, 0.001, 0.0001
PROTOCOL
*DISABLED
V1
V2
V3
When an ORION endpoint is connected to the transmitter, select the settings
to match the BEACON/AquaCUE settings. Only the flow total selected for the
Home screen will be sent.
V1 protocol does not support dial counts above 7.
Parameter Descriptions by Menu
Page 36 October 2019TTM-UM-02222-EN-04
