Badger Meter Dynasonics TFX-5000 User Manual

TFX-5000 Energy Meters for Pipes 2 in. and Smaller
DR
-
G
- - - - - - - - -
XX
- - - -
Model
TFX-5000 Ultrasonic Clamp-On Meter DR
Certification
General Area US/Canada, CE G
Transducer Type
1
1/2 inch ANSI Pipe CA
3/4 inch ANSI Pipe CB
1 inch ANSI Pipe CC
1-1/4 inch ANSI Pipe CD
1-1/2 inch ANSI Pipe CE
2 inch ANSI Pipe CF
1/2 inch Copper Tube CG
3/4 inch Copper Tube CH
1 inch Copper Tube CT
1-1/4 inch Copper Tube CJ
1-1/2 inch Copper Tube CK
2 inch Copper Tube CL
Small pipe, universal, DTTSU (not available with conduit) UZ
Transmitter Type
110/220V AC Remote Mounted R
24V DC/AC Remote Mounted B
Display
Display and Keybad S
No Display/Keypad W
Remote Cable Length
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
Conduit Type and Length (Conduit length is less than or equal to cable length)
None WW
5 feet (1.5 m) AA
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
RTD Type
Surface, Commercial C
None (user provided) X
RTD Length
15 feet AC
50 feet AK
100 feet BW
None (user provided) WW
Hardware
1/2 in. NPT Threads, Poly cable glands S
1/2 in. NPT Threads, Nickel Plated Brass cable glands T
1/2 in. NPT Threads, no cable glands N
Endpoint Wiring Method
None XX
Communication/Output
Standard Output (Modbus RTU or BACnet MS/TP field selectable) S
Standard Output plus Modbus TCP Ethernet T
Standard Output plus EtherNet/IP U
Standard Output plus BACnet/IP Ethernet V
Standard Output plus Auxilliary Dry Contact Output 9
Units of Measure Totalizer/Flow Rate
Gallons/gallons per minute (field selectable, additional options available) G
Units of Measure Energy Totalizer/Rate
Kilowatt-hour/Watt (field selectable, additional options available)
R
Testing & Tagging
Factory Calibrated
F
Factory Calibrated/Stainless Steel Tag
S
1
Stainless steel tube 1/2…2 in. options are available.
Part Number Construction
Page 57 October 2019 TTM-UM-02222-EN-04
