Badger Meter Dynasonics TFX-5000 User Manual

Wall Mount Bracket
2.50 in.
(63.50 mm)
2.00 in.
(50.80 mm)
2.00 in.
(50.80 mm)
2.00 in.
(50.80 mm)
2.50 in.
(63.50 mm)
2.00 in.
(50.80 mm)
Figure 3: Wall mount enclosure dimensions
Panel Mount Enclosure
6.50 in.
(165.10 mm)
6.50 in.
(165.10 mm)
Torque the
cover screws
to 45 in-lb.
1.38 in.
(35.05 mm)
1.25 in.
(31.75 mm)
Customer-supplied panel
Figure 4: Panel mount enclosure dimensions
Dimensions
Page 7 October 2019 TTM-UM-02222-EN-04
