Flow Meter Energy Meter
Inputs and
Outputs
0/4…20 mA output
One 16-bit, isolated, max 800 Ohms, internal or
external power
Two 16-bit, isolated, max 800 Ohms, internal or
external power
Digital input One 5…30V DC, isolated, externally or internally sourced, reset totalizer or alarm output
Digital output
Two selectable pulse, alarm, ow direction, sink isolated
open collector, 5…30V DC, max. 50 mA externally or
internally sourced
Three selectable pulse, frequency, alarm, ow direction,
isolated open collector, 5…30V DC, externally or
internally sourced
Frequency output: 50% duty cycle, 63…10k Hz maximum frequency
Pulse (totalizer) output: 5 kHz max. output, open collector, pulse width 5…500 ms programmable
Optional: Two dry contact output for alarm or ow direction 30V DC max., 5A max.
(Ethernet not available with this option)
RTD (energy only) None
Two 2-wire, 3-wire or 4-wire Pt100/Pt1000 RTD inputs;
Range of –40…200° C; Clamp-on resistor kits available
Ports
Programming USB 2.0 mini B connector for connection to a device with SoloCUE conguration software
EIA-485
Modbus RTU command set or BACnet MS/TP; Baud rates 9600, 14400,19200, 38400, 57600, 76800, 115k;
terminating resistor selectable
Ethernet Optional 10/100 Base T RJ45, communication via Modbus TCP/IP, EtherNet/IP, or BACnet/IP with webserver
AquaCUE/BEACON Connectivity to AquaCUE/BEACON endpoint (LTE cellular)
Data Logging
Number of points
Up to 8 parameters per record. Selectable 1 second to 1 day
Transfer logs via memory card
Real Time Clock Backed up with a super capacitor, minimum of 32 days of data retention without power; Requires no servicing
MicroSD card slot 8 GB card, included with transmitter
Alarms Records 150 previous alarms, warnings or errors
Languages English
Security Four levels: Read-only, Operator, Service and Admin; 6-digit passcode number; selectable auto logout
Transducers
Model Construction
Cable Length
Max.
Pipe/Tubing Sizes
Flow Rate
Max. GPM (LPM)
Pipe/
Tubing
Materials
Protection
CA-CT
fixed small pipe
CPVC, Ultem®, Nylon cord grip
PVC cable jacket;
–40…194° F (–40…90° C)
100 ft (30 m) 0.5…2 in. (12…50 mm) 190 (720)
See
2
NEMA 6/IP67
UZ
adjustable
small pipe
CPVC, Ultem, and anodized
aluminum track system; Nickel-plated
brass connector with Teflon insulation;
PVC cable jacket
–40…194° F (–40…90° C)
100 ft (30 m) 0.5…2 in. (12…50 mm) 190 (720) NEMA 12
NZ
standard pipe
PVC, Ultem®, Nylon cord grip
PVC cable jacket;
–40…194° F (–40…90° C)
300 ft (90 m) 2.5…12 in. (DN65…DN300) 4000 (15,000) NEMA 6/IP67
RZ
standard pipe
PBT glass filled, Ultem®, Nylon cord
grip; PVC cable jacket;
–40…250° F (–40…121° C)
300 ft (90 m) 2.5…12 in. (DN65…DN300) 4000 (15,000) NEMA 6/IP67
JZ, KZ
standard pipe,
integrated rail
PBT glass filled, Ultem,
Nylon cord grip; PVC cable jacket;
–40…250° F (–40…121° C)
300 ft (90 m)
2.5…6 in. (DN65…DN150)
2.5…12 in. (DN65…DN300)
4000 (15,000) NEMA 6/IP67
WZ
standard pipe,
submersible
CPVC, Ultem, Nylon cord grip
Polyethylene cable jacket;
–40…194° F (–40…90° C)
300 ft (90 m) 2.5…12 in. (DN65…DN300) 4000 (15,000)
NEMA 6P/
IP68
HZ
high temperature
PTFE, Vespel, Nickel-plated
brass cord grip; FEP cable jacket;
–40…350° F (–40…176° C)
300 ft (90 m) 2.5…12 in. (DN65…DN300) 4000 (15,000) NEMA 6/IP67
LZ
large pipe
CPVC, Ultem, Nylon cord grip
PVC cable jacket;
–40…194° F (–40…90° C)
300 ft (90 m) 8…48 in. (DN200…DN1200)
3, 4
33,000 (125,000) NEMA 6/IP67
YZ
large pipe,
submersible
CPVC, Ultem, Nylon cord grip
Polyethylene cable jacket;
–40…194° F (–40…90° C)
300 ft (90 m) 8…48 in. (DN200…DN1200)
3, 4
33,000 (125,000) NEMA 6/IP68
Recommendations based on unlined, new pipes with water. Recommended pipe or tubing sizes vary with pipe conditions and uid.
PVC, CPVC, HDPE, PTFE, PDVF, stainless steel, ductile iron, aluminum, brass naval, carbon steel copper.
Large pipe transducers are recommended for 8…12 in. pipes if normal velocity is expected to be greater than 12 ft/s (3.6 m/s).
Consult factory for larger pipe sizes.
Specications
Page 51 October 2019 TTM-UM-02222-EN-04
