SPECIFICATIONS
System
Liquid Types Most clean liquids or liquids containing small amounts of suspended solids or gas bubbles
Flow Accuracy
Medium and Large Pipes (RZ,
NZ, WZ, HZ, LZ, YZ, JZ, KZ)
± 0.5% ± 0 0.049 ft/s (0.015 m/s)
Small Pipes (CA-CT, UZ)
1 in. (25 mm) and larger = ±1% ± 0.03 ft/s (0.009 m/s)
3/4 in. (19 mm) and smaller = ±1% of full scale
Repeatability 0.2% above 1.5 ft/s
Velocity
Medium and Large Pipes Up to 40 ft/s, depending on pipe and fluid
Small Pipes Up to 20 ft/s, depending on pipe and fluid
Certification and
Compliance
General Safety (all models): cCSAus, CE, Pollution Degree 2, CE compliance to Low Voltage Directive, 2014/35/EU
Hazardous Location transmitter and transducers:
CSA-c-us Class I Division 2 Groups ABCD T4
Requires flexible conduit
Not available with UZ, HZ or JZ and KZ (Easy Rail) transducers, Auxiliary Dry Contact card or units with AquaCUE/BEACON endpoints
Transmitter
Power Options
24V DC/AC 9…28V DC @ 8 W max. or 20…26 AC 47…63 Hz @ 0.5 A max., 2 Amp slow-blow fuse, not eld replaceable
Mains AC
85…264V AC 47…63 Hz @ 24VA max. 1 Amp slow-blow fuse, manually eld replaceable
Over-Voltage Rating Category II (CAT II)
Display
Options Display with keypad or no display/keypad
Keypad 4-button navigation, keypad with tactile feedback; polyester lm
Display 128 × 64 pixel LED backlit graphical display; adjustable brightness and timeout; polycarbonate window
Flow rate/total 8-digit
Enclosure NEMA Type 4, IP67
Construction
Aluminum construction; painted; wall, panel or pipe mounting; stainless steel fasteners and mounting hardware; EPDM gasket
Conduit Holes (4) 1/2 in. NPT, M20 × 1.5 or 1/2 BSPP; cable glands available for NPT and M20
Environmental
Ratings
Pollution Degree 2
Altitude Restriction Up to 2000 m (6561 ft)
Ambient Temperature Range –4…140° F (–20…60° C)
Storage Temperature Range –40…176° F (–40…80° C)
Humidity 0…85%, non-condensing
Conguration Via optional keypad or SoloCUE conguration software; SoloCUE available on DVD
Units
(Field-
Selectable)
Velocity feet/second, meters/second
Volumetric total
US Gallons, Million Gallons, Imperial Gallons, Million Imperial Gallons, Acre-Feet, Liters, Hectoliters,
Cubic Meters, Cubic Feet, Oil Barrels (42 gallons), Fluid Barrels (31.5 gallons), Imperial Fluid Barrels
(36 imperial gallons), Pounds (Kilograms) and custom units
Flow rate
Acre Feet/Day, Liters/Second, Liters/Minute, Liters/Hour, Cubic Meters/Second, Cubic Meters/Minute,
Cubic Meters/Hour, Cubic Feet/Minute, Cubic Feet/Minute, Cubic Feet/Hour, Gallons/Second,
Gallons/Minute, Gallons/Hour, Million Gallons/Day, Imperial Gallons/Second, Imperial Gallons/Minute,
Imperial Gallons/Hour, Million Imperial Gallons/Day, Oil Barrels/Day, Fluid Barrels/Day,
Imperial Fluid Barrels/Day and custom units
Energy total
(energy meters)
British Thermal Unit (Btu), Thousand Btu, Millions Btu, Kilocalories, Mega calories, Kilowatt-hour,
Megawatt hour, Kilojoules, Mega joules, Ton-hour (Refrigeration)
Heat/cooling rate
(energy meters)
Btu/hour, Thousand Btu/hour, Millions Btu/hour, Ton (Refrigeration), Watts, Kilowatts, Megawatts,
Kilojoules/hour, Mega joules/hour, Kilocalories/hour, Mega calories/hour
Specications
Page 50 October 2019TTM-UM-02222-EN-04
