12. Alignment
Image 12-151
Scenergix, Black level
2. Press ENTER to select and use the ▲ or ▼ key to select a color to adjust or select All colors to adjust all colors at the same time.
Image 12-152
Black level, adjust
3. Adjust the black level of area A until the black level of area A, B and C are equal. Use the Adjust function Red, Green and Blue
in the Black level menu.
A
C
B
12
13
11
R
G
B
RGB
Image 1
Image 2
Image 12-153
Black level adjustment
Use the Reset item to set all values back to zero.
12.14.9 Scenergix Reset
What can be done?
All Scenergix values can be set back to the default values.
212
R5905032 HDX SERIES 20/11/2014
