Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________12
• RV
Reads the current brightness
Example: RV,BRI
Response: 50
• MM
Returns the maximum brightness
Example: MM,BRI
Response: 200
• Mm
Returns the minimum brightness
Example: Mm,BRI
Response: 0
4.5.2. CON
Adjusts and gets information about the contrast of the display.
Command Minimum to Maximum Contrast
CMD 0 - 200
RV
MM
Mm
CON
• CMD
Sets contrast value
Example: CMD,CON,50
Response: 50
• RV
Reads the current contrast
Example: RV,CON
Response: 50
• MM
Returns the maximum contrast
Example: MM,CON
Response: 200
• Mm
Returns the minimum contrast
Example: Mm,CON
Response: 50
4.5.3. SAT (Color in OSD)
Adjusts and gets status about the saturation/color for the display.
Command Minimum to Maximum Saturation
CMD 0 - 200
RV
MM
Mm
SAT

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
