Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________36
• MM
Returns maximum language number
Example: MM,LAN
Response: 4
• Mm
Returns minimum language number
Example: Mm,LAN
Response: 1
4.9.8. OSDT
This command selects how long it will take for the OSD to timeout or disappear after the
last key press.
Command Resulting Time Out
CMD
1
2
3
4
5
15 seconds
30 seconds
45 seconds
1 minute
4 minute
RV
MM
Mm
OSDT
• CMD
Sets the OSD time out
Example: CMD,OSDT,3
Response: 3
• RV
Reads the OSD time out
Example: RV,OSDT
Response: 3
• MM
Returns maximum OSD time out
Example: MM,OSDT
Response: 5
• Mm
Returns minimum OSD time out
Example: Mm,OSDT
Response: 1
4.9.9. GPIO
This command enables the GPIO interface selecting between 4 types of functionality:
disabled, switch input, show text and PIP order. It can also read what currently
selected function is for the GPIO.

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
