Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________38
• CMD
Sets the GPIO text
Example: CMD,GPIOT,1,camera 3
Response: camera 3
Example: CMD,GPIOT,2,camera 1
Response: camera 1
• RV
Reads the GPIO text
Example: RV,GPIOT,1
Response: camera 3
Example: RV,GPIOT,2
Response: camera 1
• MM
Returns maximum number of characters for the GPIO text
Example: MM,GPIOT
Response: 11
• Mm
Returns minimum number of characters for the GPIO text
Example: Mm,GPIOT
Response: 1
4.9.11. GPIOP (in text mode only)
This command assigns one of six positions for the GPIO text or reads the position that is
currently set. Positions start at [1] upper left corner and go clock wise to [2] upper
middle, [3] upper right, [4] lower right, [5] lower middle, and [6] lower left.
New coordinates will only take affect when text is drawn again. Existing text box will be
erased.
Command Image Function
CMD
1 / 2
[1] = Upper left
[2] = Upper middle
[3] = Upper right
[4] = Lower right
[5] = Lower middle
[6] = Lower left
RV 1 / 2
MM
Mm
GPIOP
• CMD
Sets the GPIO position
Example: CMD,GPIOP,1,3
Response: 1
Example: CMD,GPIOP,2,6
Response: 2

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
