Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________27
• MM
Returns the maximum luminance
Example: MM,BKL
Response: 100
• Mm
Returns the minimum luminance
Example: Mm,BKL
Response: 0
4.8.2. PHZ
Adjusts and gets status about the phase settings of the display.
Command Minimum – Maximum Phase
CMD 0 - 31
RV
MM
Mm
PHZ
• CMD
Sets phase value
Example: CMD,PHZ,15
Response: 15
• RV
Reads the current phase value
Example: RV,PHZ
Response: 15
• MM
Returns the maximum phase value
Example: MM,PHZ
Response: 31
• Mm
Returns the minimum phase value
Example: Mm,PHZ
Response: 0
4.8.3.
FRQ
Adjusts and gets status about the frequency settings of the display.
Command Minimum – Maximum Frequency
CMD 500 - 2800
RV
MM
Mm
FRQ

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
