Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________45
• MM
Returns maximum bandwidth value
Example: MM,BWV
Response: 170
• Mm
Returns minimum bandwidth value
Example: Mm,BWV
Response: 0
4.11.8. CLP
This command clears all presets or user modes
Command
CMD
CLP
• CMD
Sets bandwidth value
Example: CMD,CLP
Response: ACK
4.11.9. CLMP
This command turns clamp width adjust on/off for certain inputs. Clamp width is only
available with some input types see online user manual for details.
Command
CMD
0/1
RV
MM
Mm
CLMP
• CMD
Sets clampwidth manual
Example: CMD,CLMP,1
Response: 1
• RV
Reads clampwidth off/on
Example: RV,CLMP
Response: 1
• MM
Returns: 1 = enabled
Example: MM,CLMP
Response: 1
• Mm
Returns: 0 = disabled
Example: Mm,CLMP
Response: 0

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
