Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________16
Command Scale Number Resulting Scaling
CMD 1
2
3
4
5
6
= Native
= Best Fit
= Fit Height
= Fit Width
= Full Display
= Adjustable
RV
MM
Mm
SCL
• CMD
Sets scale select value
Example: CMD,SCL,5
Response: Scaling: Full Display
• RV
Reads the current scale select value
Example: RV,SCL
Response: Scaling: Full Display
• MM
Returns the maximum scale select value
Example: MM,SCL
Response: 6
• Mm
Returns the minimum scale select value
Example: Mm,SCL
Response: 1
4.5.11. SCLA
This function automatically selects adjustable scaling and changes the scaled value from
50% to 200%. Limitations in the Gennum will prevent scaling for some high frequency
HDTV inputs.
Command Adjustable Scaling Value
CMD 50 – 200
RV
MM
Mm
SCLA
• CMD
Sets scale select adjustable value. Makes scaling adjustable.
Example: CMD,SCLA,100
Response: 100
• RV
Reads the current adjustable scaled value
Example: RV,SCLA
Response: 100

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
