Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________28
• CMD
Sets frequency value
Example: CMD,FRQ,400
Response: 400
• RV
Reads the current frequency value
Example: RV,FRQ
Response: 400
• MM
Returns the maximum frequency value
Example: MM,FRQ
Response: 2800
• Mm
Returns the minimum frequency value
Example: Mm,FRQ
Response: 500
4.8.4. CTMPV
This command selects the active color temperature: Full White, 5300K, 6500K, 9300K,
Clear Base, Blue Base, User or any of the adjustable values. Certain values such as
5300K, 6500K and 9300K can be selected by 2 different values to remain compatible
with previous versions of firmware that do not have extended color values.
Command Color Temperature Number
CMD
CTMPV
[1] = Full White/Native White
[2] = 5300K
[3] = 6500K
[4] = 9300K
[5] = Clear Base
[6] = Blue Base
[7] = Adjustable (last adjustable value set)
[8] = User
[9] = 5000K
[10] = 5200K
[11] = 5300K
[12] = 5400K
[13] = 5600K
[14] = 5800K
[15] = 6000K
[16] = 6200K
[17] = 6400K
[18] = 6500K
[19] = 6600K
[20] = 6800K

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
