Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________19
• CMD
Sets PIP layout value
Example: CMD,PIPL,4
Response: 4
• RV
Reads the current PIP layout
Example: RV,PIPL
Response: 4
• MM
Returns the maximum PIP layout number
Example: MM,PIPL
Response: 4
• Mm
Returns the minimum PIP layout number
Example: Mm,PIPL
Response: 0
4.6.2. PIPSL
PIPSL will save the current PIP layout to the active PIP layout number. The layout you
wish to save must be active when the PIPSL command is executed.
Command
CMD
RV
PIPSL
• CMD
Saves current PIP layout
Example: CMD,PIPSL
Response: 3 (when PIP layout 4 is set)
• RV
Reads the current PIP layout number
Example: RV,PIPSL
Response: 3 (when PIP layout 4 is set)
4.6.3. PIPDL
This command deletes an active PIP layout. The layout you wish to delete must be
active when the PIPDL command is executed.
Command
CMD
RV
PIPDL
• CMD
Deletes current PIP layout
Example: CMD,PIPDL
Response: 3 (when PIP layout 3 is set)

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
