Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________30
• RV
Reads the current color user type gain values
Example: RV,UCTMP
Response: User:780;200;1000
• MM
Returns the maximum gain value
Example: MM,UCTMP
Response: 1000
• Mm
Returns the minimum gain value
Example: Mm,UCTMP
Response: 10
4.8.6. DFC
Selects display function: Native, Gamma or DICOM.
Command Display Function
CMD
[1] = Native
[2] = Gamma
[3] = DICOM
RV
MM
Mm
DFC
• CMD
Sets display function / LUT type
Example: CMD,DFC,3
Response: DICOM
• RV
Reads the current display function / LUT type
Example: RV,DFC
Response: [1-3]
• MM
Returns the maximum display function / LUT type
Example: MM,DFC
Response: 3
• Mm
Returns the minimum display function / LUT type
Example: Mm,DFC
Response: 1
4.8.7. DFG
Display gamma value, automatically selects Gamma for display function.

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
