Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________26
4.7.4. SNP
This command saves a new profile in the first available (not used or deleted) profile.
Command
CMD
SNP
• CMD
Saves the current settings as a new profile returns number
Example: CMD,SNP
Response: 3
4.7.5. SCP
This command saves the profile in the current profile selected. All existing values for
that profile will be overwritten.
Command
CMD
SCP
• CMD
Saves the current settings and overwrites currently selected profile.
Example: CMD,SCP
Response: 3
4.8. Advanced commands
4.8.1. BKL (Luminance in OSD)
Adjusts and gets status about the backlight settings (luminance in the OSD) for the
display.
Command Minimum – Maximum Luminance
CMD 0 - 100
RV
MM
Mm
BRI
• CMD
Sets luminance value
Example: CMD,BKL,50
Response: 50
• RV
Reads the current luminance
Example: RV,BKL
Response: 50

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
