Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________43
Command
CMD
0 / 1
RV
MM
Mm
KEYM
• CMD
Sets the menu key enabled / disabled
Example: CMD,KEYM,0
Response: 0
• RV
Reads whether the keyboard beep enabled / disabled
Example: RV,KEYM
Response: 0
• MM
Returns enabled value
Example: MM,KEYM
Response: 1
• Mm
Returns disabled value
Example: Mm,KEYM
Response: 0
4.11.5. GMT
This command adjusts gamut the balance of red and green in an image.
Command
CMD
[70-100]
RV
MM
Mm
GMT
• CMD
Sets the color gamut value between 70 and 100
Example: CMD,GMT,85
Response: 85
• RV
Reads color gamut value
Example: RV,GMT
Response: 85
• MM
Returns maximum gamut value
Example: MM,GMT
Response: 100
• Mm
Returns the minimum gamut value
Example: Mm,GMT
Response: 70

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
