Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________32
Command Input Enable/Disable
CMD
1 – total number of
inputs
1 / 0
RV
MM
Mm
ENI
• CMD
Enables or disables input
Example: CMD,ENI,1,0
Response: VGA Disabled
• RV
Reads whether the input is disabled / enabled
Example: RV,ENI,1
Response: VGA Disabled
• MM
Returns maximum number of inputs, this can vary for display types.
Example: MM,ENI
Response: 13
• Mm
Returns the minimum input number
Example: Mm,ENI
Response: 1
4.9.2. QIN
This command enables or disables the quick input select feature using the up and down
keys on the display.
Command Enable/Disable
CMD
0 / 1
RV
MM
Mm
QIN
• CMD
Sets the quick input select is enabled / disabled
Example: CMD,QIN,0
Response: 0
• RV
Reads whether the quick input select is enabled / disabled
Example: RV,QIN
Response: 0
• MM
Returns enabled value
Example: MM,QIN
Response: 1

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
