Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________46
4.11.10. CLMPV
This command turns clamp width adjust on/off for certain inputs. Clamp width is only
available with some input types see online user manual for details.
Command
CMD
5-100
RV
MM
Mm
CLMPV
• CMD
Sets clampwidth value
Example: CMD,CLMPV,75
Response: 75
• RV
Reads clampwidth value
Example: RV,CLMPV
Response: 75
• MM
Returns: 100
Example: MM,CLMPV
Response: 100
• Mm
Returns: 5
Example: Mm,CLMPV
Response: 5
4.12. ASCII Specific Commands
4.12.1. DPMS
This command enables and disables standby mode. Coming out of standby takes
several seconds.
Command
CMD
0/1
RV
MM
Mm
DPMS
• CMD
Enables / disables DPMS
Example: CMD,DPMS,1
Response: 1

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
