Barco MDSC-1119 User Manual

Overview of Commands
MDSC-1119 and MDSC-2124_________________________________________________________________17
• MM
Returns the maximum scale select value
Example: MM,SCLA
Response: 200
• Mm
Returns the minimum scale select value
Example: Mm,SCLA
Response: 50
4.5.12. ASRI
This commands selects the aspect ratio of the image: Auto, 1/1,5/4,16/9 or adjustable.
When using “auto” selection the best aspect ratio for an input is determined by the
VESA table in the display.
Command Aspect Ration Number Resulting ASR
CMD 0
1
2
3
4
5
= Auto
= 1/1
= 4/3
= 5/4
= 16/9
= Adjustable
RV
MM
Mm
ASRI
• CMD
Sets aspect ratio
Example: CMD,ASRI,4
Response: 4
• RV
Reads the current aspect ratio
Example: RV,ASRI
Response: 4
• MM
Returns the maximum aspect ratio
Example: MM,ASRI
Response: 5
• Mm
Returns the minimum aspect ratio
Example: Mm,ASRI
Response: 0
4.5.13. ASRV
This command changes the aspect ratio adjustable value. When the ASRV command is
used the adjustable setting of ASRI (aspect ration type) is automatically set. Values go
from 800-2000.

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
