Barco MDSC-1119 User Manual

Command Protocol
MDSC-1119 and MDSC-2124__________________________________________________________________7
the parameter to set the value “75” is only needed for a “CMD” or write type command.
Sending extra parameters that are not needed will generate an error message response.
The same command can also be written as follows:
& &
Byte 1 Byte 2
0x26 0x26
ASCII
HEXADECIMAL
B
Byte 7 Byte 8
K L
,
7
Byte 9 Byte 10 Byte 11 Byte 12
5
Byte 13
;
0x42 0x4B
0x4
C
0x2
C
0x37 0x35 0x3B
C M
Byte 3 Byte 4
0x43
0x4
D
D
Byte 5
0x44
,
Byte 6
0x2
C
Control Command Response
The new Backlight value written is the response.
7 5
Byte 1 Byte 2
0x37 0x35
ASCII
HEXADECIMAL
3.3.2. Read Value command (RV)
When the “RV” (read value) characters are sent at the beginning of the command the
response returns the value or status and does not execute any action.
RV Command Example
To use the same command to read the ASCII characters “RV” are sent just after the two
start characters “&&” and separated from the “BKL” command with a “,”.

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
