56-101-01175 Revision H Page | 61
5. Select the appropriate Limit values for the aircraft / Instrument’s to be tested.
Note: If the appropriate limits file does not exist go into Setup 2 and create the limit
file:
a) From Main Menu touch blue icon “page 2”. A screen is displayed with four
options ( Setup 1, Setup 2, Setup 3 and Change User Pin#)
b) Select Setup 2. A key pad screen appears.
c) Input user PIN (default PIN: 123456). A screen is displayed.
d) Touch Limits Create/Edit/Delete. A key pad screen appears.
e) Create Custom Limits - enter the parameter values for ALT, ROC, CAS, RtCAS,
MACH, and ALR (Auto Leak Recovery).
CAUTION: Using incorrect limits can cause damage to sensitive components and
aircraft systems.
Note: Before creating new limits refer to the appropriate AMM (Aircraft Maintenance
Manual) or CMM (Component Maintenance Manual) for the actual minimum
and maximum values to be applied.
6. Enter the Altitude Correction value if required.
a) From main menu, touch blue icon “page 2”. A screen with four options appears.(
Setup 1, Setup 2, Setup 3 and Change User Pin#).
b) Touch Setup 1. A screen with four options is displayed.
c) Select altitude Correction. A yellow window with a message is displayed.
d) Read message, select “Ok”. The “ALT Correction” numbered key pad panel
opens
e) Enter Altitude correction value. The height difference between the aircraft system
or instrument under test and the DPS1000 Test Set.
7. Using the AMM or CMM, select the appropriate Leak Test ATP Leak Test Profile.
a) From main menu, select Leak Testing. The Leak Testing panel opens.
b) Touch ATP Leak Test Profiles. The ATP Leak Profiles panel is displayed.
c) Select the appropriate profile to perform the Leak Test as specified by the AMM
or CMM
d) If required, the default ATP profile can be selected and the parameters can be
changed to the values specified by the AMM or CMM.
