Appendix B: Operating Limits
The DPS1000 comes with 2 pre-defined sets of operating limits: the default limits profile and the
max limits profile. The unit also includes limits files for each of the three operating modes:
Aeronautical, Pressure units and EPR. Each of these three operating modes contains a default
limits profile and a max limits profile. The values for both limits profiles are stored in an R/O “read
only” file. The Test Set will first power up and initialize with the default limits profile. If the customer
changes the limits to the max or a custom limits profile, the Test Set will power up using the last
profile selected.
The following tables represent the default and max limits profile values included in the DPS1000:
Aeronautical Limits Profile – (default)
Parameters
Limits
Comments
ALT Min
-1,500 ft { -460 m }
Minimum Target Altitude
ALT Max
50,000 ft { 15,240 m}
Maximum Target Altitude
ROC Min
100 ft/min { 30 m/min}
Minimum Target ROC
ROC Max
6,000 ft/min {1,830 m/min}
ROC - (default)
3,000 ft/min {900 m/min}
CAS Min
0.0 kts
Target = 0.0 or >= 5.0 kts
CAS Max
500 kts { 926 km/h}
RtCAS Min
50 kts/min { 100 km/h/min}
RtCAS Max
450 kts/min { 850 km/h/min}
RtCAS – (default)
300 kts/min {550 km/h/min}
MACH Min
0.03
Target = 0.0 MACH or >=0.03
MACH Max
0.90
ALT Correction Min
-100 {-30 m}
ALT Correction Max
+100 { 30 m}
ALR: Auto Leak Recovery
Enabled (default)
ALR: ROC
1,000 ft/min {300 m/min}
ALR: RtCAS
100 kts/min {185 km/h/min}
Table 7 Aeronautical Limits Profile – (default)
Aeronautical Limits Profile – (max)
Parameters
Limits
Comments
ALT Min
-2,000 ft { -610 m }
Minimum Altitude
ALT Max
55,000 ft { 16,765 m }
ROC Min
100 ft/min { 30 m/min}
ROC Max
20,000 ft/min {6,000 m/min }
ROC – (default)
3,000 ft/min {900 m/min}
CAS Min
0.0
CAS Max
650 kts {1,200 km/h }
RtCAS Min
50 kts/min {95 m/min }
RtCAS Max
600 kts/min {1,000 km/h/min }
MACH Min
0.00
MACH Max
3.0
ALT Correction Min
-100
ALT Correction Max
+100
ALR: Auto Leak Recovery
Enabled (default)
ALR: ROC
2,000 ft/min {600 m/min}
ALR: RtCAS
200 kts/min {370 km/h/min}
Table 8 Aeronautical Limits Profile – (max)
