56-101-01175 Revision H Page | 80
Operating Limits (con’t)
Pressure Limits Profile – (default)
Parameters
Limits
Comments
Ps Min
2.693 inHg
Ps Minimum Pressure
Ps Max
32.000 inHg
Ps Maximum Pressure
Qc Min
0.000 inHg
Qc Minimum Pressure
Qc Max
30.000 inHg
Qc Maximum Pressure
Pt Min
2.693 inHg
Pt Minimum Pressure
Pt Max
62.000 inHg
Pt Maximum Pressure
PsRt Min
0.10 inHg/min
Ps Minimum Rate
PsRt Max
16.0 inHg/min
Ps Maximum Rate
QcRt Min
0.50 inHg/min
Qc Minimum Rate
QcRt Max
10.0 inHg/min
Qc Maximum Rate
Table 9 Aeronautical Limits Profile – (default)
Pressure Limits Profile – (max)
Parameters
Limits
Comments
Ps Min
2.693 inHg
Ps Minimum Pressure
Ps Max
38.000 inHg
Ps Maximum Pressure
Qc Min
0.000 inHg
Qc Minimum Pressure
Qc Max
40.000 inHg
Qc Maximum Pressure
Pt Min
2.693 inHg
Pt Minimum Pressure
Pt Max
78.000 inHg
Pt Maximum Pressure
PsRt Min
0.50 inHg/min
Ps Minimum Rate
PsRt Max
10.0 inHg/min
Ps Maximum Rate
PsRt – (default)
3.0 inHg/min
Ps default Rate
QcRt Min
0.10 inHg/min
Qc Minimum Rate
QcRt Max
10.0 inHg/min
Qc Maximum Rate
QcRt – (default)
3.0 inHg/min
Qc default Rate
Table 10 Aeronautical Limits Profile – (max)
