Baumer EA Series User Manual

Baumer_EAx_EtherNetIP_EN_MNL 74/81 www.baumer.com
02.20
7.16. TCP/IP Interface Object (0xF5)
The TCP/IP Interface Object provides the mechanism to configure a device’s TCP/IP network interface.
Examples of configurable items include the device’s IP address, network mask and gateway address.
The TCP/IP Interface Object provides an attribute that identifies the link-specific object for the associated
physical communications interface. The link-specific object is generally expected to provide link-specific
counters as well as any link-specific configuration attributes.
7.16.1. Class Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
0x01
Get_Attributes_All
Returns the contents of the
instance or class attributes
defined in the object definition
0x10
Set_Attribute_Single
Modifies an attribute value
7.16.2. Class Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
Semantics of
Values
Value
1
Get
Revision
UINT
Revision of this
object
The current value
assigned to this
attribute is four
(04).
4
2
Get
Max
Instance
UINT
Maximum instance
number of an
object
currently created in
this class level of
the device
The largest
instance number of
a created object at
this class hierarchy
level
1
7.16.3. Instance Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
0x10
Set_Attribute_Single
Modifies an attribute value by
applying and saving the value
to the non-volatile memory
