7.13.2. Class Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
Semantics of
Values
Value
1
Get
Revision
UINT
Revision of this object
-
2
2
Get
Max
Instance
UINT
Maximum instance
number of an object
currently created in
this class level of the
device.
The largest instance
number of a created
object at this class
hierarchy level.
1
3
Get
Number
of
Instances
UINT
Number of object
instances currently
created at this class
level of the device.
The number of
object instances at
this class hierarchy
level.
1
4
Get
Optional
attribute
list
Struct
of
List of optional
instance attributes
utilized in an object
class implementation.
A list of attribute
numbers specifying
the optional
attributes
implemented in the
device for this class.
number
of
attributes
UINT
Number of attributes in
the optional attribute
list.
The number of
attribute numbers in
the list.
8
optional
attributes
ARRAY
of UINT
List of optional
attribute numbers
The optional
attribute numbers.
3,11,14,16,17,
19,42,50
6
Get
Maximum
ID
Number
Class
Attributes
UINT
The attribute ID
number of the last
class attribute of the
class definition
implemented in the
device.
7
7
Get
Maximum
ID
Number
Instance
Attributes
UINT
The attribute ID
number of the last
instance attribute of
the class definition
implemented in the
device
See Instance
Attributes
7.13.3. Instance Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
0x10
Set_Attribute_Single
Modifies an attribute value
