Baumer EA Series User Manual

Baumer_EAx_EtherNetIP_EN_MNL 48/81 www.baumer.com
02.20
Attribute 8 (State)
The meaning of the bits of attribute 8 is described in the following table.
Value
Description
0
Not existent
1
Device Self Testing
2
Standby
3
Operational
4
Major Recoverable Fault
5
Major Unrecoverable Fault
6-254
Reserved
255
Not supported
7.10. Message Router Object (0x02)
The Message Router Object provides a messaging connection point through which a client may
address a service to any object class or instance residing in the physical device. Since the message
router does not have any class or instance attributes there are no services supported.
7.11. Assembly Object (0x04)
The Assembly Object binds attributes of multiple objects which allows data to or from each object to be sent
or received over a single connection. Assembly Objects can be used to bind input data or output data. The
terms ”input” and ”output” are defined from the network’s point of view. An input will produce data on the
network and an output will consume data from the network.
7.11.1. Class Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
7.11.2. Class Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
Semantics of
Values
Value
1
Get
Revision
UINT
Revision of this
object
The current value
assigned to this
attribute is two (02).
If updates that
require an increase
in this value are
made, then the
value of this
attribute increases
by 1.
2
